36~30AWG Mini USB 3.0 cable, UL 20276

28 Jul 2019

Description：

• Rated temperature: 80℃
• Rated voltage: 30V
• Reference standard: UL758, UL1581, USB3.0 specification
• Stranded bare or tinned copper conductor
• FEP or foam PE insulation
• Shielded with AL-Myar and braiding
• Lead-free PVC or FRPE jacket
• Flammability grade: UL VW-1 & CSA FT1 vertical flame test

Electrical Characteristics:

• Differential Impedance（20℃）：90±10
• Propagation delay skew: within a pair: ≤15ps/m

Next:

• 100MHz ≤12
• 1.25GHz ≤50
• 2.5GHz ≤7.5
• 7.5GHz ≤25

Construct

Conductor

Insulation

Inner Sheilded

Out Sheilded

Jacket

Style

Pair

AWG

Stranding

mm

Wall/mm

Material

OD mm

Drain

Al-myar

Al-myar

Sheilded/Spiral

Wall

O.D.

36AWG USB3.0

2P

36AWG

7/0.05

0.15

0.10

FEP

0.36

7/0.05

Y

Y

16/8/0.06

0.51

3.30

1P

32AWG

7/0.08

0.24

0.11

HD-PE

0.46

2C

28AWG

7/0.127

0.38

0.12

HD-PE

0.63

34AWG USB3.0

2P

34AWG

7/0.06

0.18

0.13

FEP

0.44

7/0.06

Y

Y

16/8/0.06

0.51

3.60

1P

32AWG

7/0.08

0.24

0.11

HD-PE

0.46

2C

28AWG

7/0.127

0.38

0.12

HD-PE

0.63

32AWG USB3.0

2P

32AWG

7/0.08

0.24

0.18

FOAM-PE

0.60

7/0.08

Y

Y

16/8/0.08

0.51

4.10

1P

32AWG

7/0.08

0.24

0.11

HD-PE

0.46

2C

28AWG

7/0.127

0.38

0.12

HD-PE

0.63

30AWG USB3.0

2P

30AWG

7/0.10

0.30

0.21

FOAM-PE

0.72

7/0.10

Y

Y

16/6/0.10

0.51

4.50

1P

30AWG

7/0.10

0.30

0.12

HD-PE

0.55

2C

28AWG

7/0.127

0.38

0.12

HD-PE

0.63

• Reference：UL iQ Style Page : UL 20276
