Ul3135 hight temperature silicone wire
24 Oct 2018Description:
- Tinned, annealed, stranded or solid copper conductor.
- Silicone indulation.
- Rated temperature: 200℃, Rated voltage:600 Volts.
- Uniform thickness of wire to ensure easy stripping and cutting.
- Passes UL VW-1&Cul FT1 vertical flame test.
Reference Standard:
- UL758, UL1581,CSA22.2
- Resistant acids,oil,aldalis,moisture and fungus.
Application:
- For general pupose internal wiring of electronic and electrical equipment.
| AWG | Stranding(mm) | Wall | OD |
|---|---|---|---|
| 26 | 7/0.15 | 0.76 | 2.0±0.05 |
| 24 | 14/0.14 | 0.81 | 2.2±0.05 |
| 22 | 12/0.14 | 0.79 | 2.36±0.05 |
| 20 | 20/0.18 | 0.79 | 2.48±0.05 |
| 18 | 30/0.18 | 0.78 | 2.78±0.05 |
| 16 | 50/0.18 | 0.79 | 3.0±0.05 |
| 14 | 80/0.18 | 0.76 | 3.5±0.05 |
| 12 | 65/0.18 | 0.77 | 4.5±0.05 |
OD: overall diameter
Application:
- For general pupose internal wiring of electronic and electrical equipment.
